Flat Face Couplings & Applications


Magnum series offers higher pressure ratings, superior flow ratings, lower pressure drop.


Flat face couplers are specifically designed for applications needing no-leak performance. The mating faces are easily cleaned before connecting, making it the ideal solution for limiting contamination in a hydraulic circuit. The design allows applications involving high pressure impulses in agriculture equipment, mobile construction equipment and general industrial plants. Non-spill design avoids fluid loss in connection and disconnection.

- Seals: Viton, EPDM,
- Threads: NPT, SAE,BSPT

Series: FF Magnum

  • Inter change: ISO 16028
  • Size: 1/4" to 1"
  • Flat face FF Magnum series couplings are in accordance with ISO 16028.
  • The interchangeability of size 10 is also in accordance with NFPA T3.20.15 (HTMA).
    - Seals: Nitrile and Teflon anti-extrusion
    - Nipple: hardened steel reduces brinnelling
    - 12 to 20 balls to increase the male bearing points & decrease the brinelling effect
    - Exceeds impulse test of ISOA-7241 test

Download - Flat Face Couplings Catalog
